High Temperature Automotive Wires
(HTAW™)

HTAW™ automotive wires for continuous use at operating temperatures of up to -40ºC to +150°C (Class D), + 200ºC (Class F) and +250ºC (Class H), confirm first mover status in the development of forward-looking product technology. This new generation of automotive wires are suitable for vehicles with hybrid power trains and for fuel cell wiring applications.

  • -40°C to +150°C (Class D)
  • -40°C to +200°C (Class F)
  • -40°C to +250°C (Class H)

DESIGN CHARACTERISTICS :

  • Conductor : Soft annealed electrolytic copper, Bare or Tinned or Silvered.
  • Insulation : High Temperature Fluro Polymer, with properties similar to ISO6722.


Conductor Design Insulated Wire
Nominal Type A Type B Maxlmurn Conductor Nominal Nominal Weight
Cross-Section Stranding/ Stranding/ Dia. of Resistance at Wall Overall
Area No/Dia No/Dia Conductor 200C (DC) Max. Thickness Diameter Aprox.
MM2 MM MM MM Ω/Km MM MM Kg/MM
0.13 7/0.16 – 0.55 136.00 0.25 1.20 2.90
0.22 7/0.20 – 0.70 84.80 0.25 1.20 2.90
0.35 7/0.26 12/0.20 0.80 54.40 0.25 1.30 4.50
0.50 19/0.19 16/0.20 1.00 37.10 0.25 1.40 6.00
0.75 19/0.19 24/0.20 1.20 24.70 0.25 1.65 9.40
1.00 19/0.26 32/0.20 1.35 18.50 0.30 1.90 11.00
1.50 19/0.32 30/0.26 1.70 12.70 0.30 2.20 16
2.00 19/0.37 30/0.30 2.00 9.42 0.35 2.55 22.00
2.50 19/0.41 50/0.26 2.20 7.60 0.35 2.75 26.00
4.00 – 56/0.30 2.65 4.71 0.40 3.38 40.00
6.00 – 84/0.30 3.30 3.14 0.40 4.00 61.00
10.00 – 80/0.40 4.50 1.82 0.50 5.15 105.00
